FN286-6-06夏弗纳Schaffner滤波器EMI 6A 符合医疗1MOP标准

　　型号：fn286-6-06

　　品牌：夏弗纳schaffner

　　名称：滤波器

　　maximum continuous operating voltage 250 v, 50/60 hz

　　operating frequency dc to 400 hz

　　rated currents 1 to 10 a @ 40°c max.

　　high potential test voltage p –> pe 2000 vac for 2 sec (standard types)

　　p –> pe 2500 vac for 2 sec (b types)

　　p –> n 760 vac for 2 sec

　　protection category ip 40 according to iec 60529

　　temperature range (operation and storage) -25°c to +85°c (25/85/21)

　　design corresponding to ul 1283, csa 22.2 no. 8 1986, iec/en 60939

　　flammability corresponding to ul 94 v-2 or better

　　mtbf @ 40°c/230 v (mil-hb-217f) 1,500,000 hours

　　fuse holder 1 or 2 fuses (?5 x 20 mm) (certified to iec 60127-6)

　　power acceptance @ amb. temperature

　　marking max. 250 v ~ (text is print. below fuse symbol)

　　rocker switch deion

　　function 2-pole, dark not illuminated

　　marking i - 0

　　electrical specifications inrush current 82 a

　　6,000 on-off operations according to ul 1054, tv5

　　10,000 on-off operations according to enec

　　switch ratings

　　usa (ul) and canada (c-ul) 10 a, 125 vac; 10 a, 250 vac; 1/3 hp

　　europe (enec) 10 a (4 a), 250 vac*

　　mechanical life 50,000 cycles

　　其他型号：

　　fn2030bz-10-06 ; fn2030bz-1-06 ; fn2030bz-12-06 ; fn2030bz-16-06 ;

　　fn2030bz-20-06 ; fn2030bz-30-08 ; fn2030bz-3-06 ; fn2030bz-4-06 ;

　　fn2030bz-6-06 ; fn2030bz-8-06 ; fn286-6-06
