DS-1100KI Network Keyboard海康威视HIKVISION网络键盘

　　DS-1100KI Network Keyboard海康威视HIKVISION网络键盘

　　Features and Functions

　　7’’ TFT touch screen at 800×480 resolution;

　　4-axis joystick;

　　Live view and playback of video on screen at up to 1080P resolution;

　　Compatible with NVR/DVR/DVS, matrix, network camera/dome, video wall controller, etc.

　　Macro command operation;

　　Display of decoded video on monitor or video wall;

　　Shortcut keys for dome control, setting and calling of preset, patrol and pattern;

　　Shortcut keys for playback operation;

　　Shortcut keys for input group and output group;

　　Shortcut keys for wiper and light control operation;

　　1-channel video decoding for local live view;

　　Video capture and recording to local U-flash disk;

　　Support 3 operators, and each user is allowed to operate 1280 devices;

　　Support configuration by WEB server;

　　Support configuration by the Keyboard Configuration Tool;

　　Configuration and control of the MVC system;

　　Support control of the analog matrix with the protocol of ZT-1.0, ZT-2.0, EXTRON or CREATOR;

　　Control of up to 255 analog domes by RS-485 connection;

　　Accessible by the platform software.
